SPECIFICATION | UNIT | SM-630 | SM-660 | SM-700 | SM-850 | SM-1000 |
Max. Planing Length | mm | 630 | 660 | 700 | 850 | 1000 |
Max. distance between ram bottom and worktable surface | mm | 385 | 385 | 420 | 400 | 400 |
Max. horizontal travel distance of worktable | mm | 630 | 630 | 630 | 710 | 800 |
Max. vertical travel distance of worktable | mm | 360 | 360 | 320 | 360 | 380 |
Worktable | mm | 630x400 | 660x400 | 700x420 | 800x450 | 1000x500 |
Travel of tool head | mm | 120 | 120 | 125 | 160 | 160 |
Number of ram strokes/min | mm | 14,20,28,40,56,80 | 14,20,28,40,56,80 | 11,20,38,52,72,100 | 17,24,35,50,70,100 | 15,20,29,42,58,83 |
Range of table power feed | Horizontal | mm | 0.2-2.5 12 steps | | 0.15-1.5 12 steps | 0.25-3 12 steps | 0.3-3 10 steps |
Vertical | mm | 0.08-1.00 12 steps | | 0.07-0.68 10 steps | 0.12-1.5 12 steps | 0.15-0.5 8 steps |
Speed of table rapid traverse | Horizontal | mm/min | | | 0.75 | 1.2 | 3 |
Vertical | mm/min | | | 0.34 | 0.58 | 0.5 |
T-Slot width | Mm | 18 | 18 | 18 | 22 | 22 |
Main motor power | Kw | 3 | 3 | 4 | 5.5 | 7.5 |
N.W./G.W. | kg | 1750/1950 | 1870/2070 | 2700/2900 | 2940/3140 | 4870/5150 |
