X/Y/Z axis travel

mm

1000/500/580

Spindle nose to table

mm

140-720

Spindle center to column guide-way face

mm

520

High speed feeding of X,Y, axis

mm/min

15000

High speed feeding of Z axis

mm/min

12000

Feeding speed

mm/min

1-5000

Size of table

mm

1600×500

Max. loading capacity of table

kg

900

T-slot NO./width /distance of table

5/18/80

Spindle max. speed

r/min

80-3500

Main motor rated power

kw

11/15

Spindle nose taper

BT50

Magazine capacity

pc

16/20(option)

Max. diameter of tools

mm

Φ152 /Φ200

Max. length of tools

mm

300

Max. weight of tools

kg

15

X/Y/Z to ac servo motor

nm

11

N.W

kg

6900

Overall dimension

mm

3500×2450×2400
